Core 12V 200Ah Lithium Iron Phosphate Battery w/ Bluetooth

Overview

The Renogy Core 12V 200Ah Lithium Iron Phosphate Battery w/ Bluetooth is designed for long-lasting, reliable power wherever you need it. Whether for off-grid cabins, RVs, solar setups, or marine applications, this LiFePO4 battery offers consistent performance, extended lifespan, and real-time monitoring through Bluetooth for effortless energy management.

Benefits

• Stay powered longer: Enjoy up to 4000+ charge cycles, giving you years of dependable energy without frequent replacements.
• Peace of mind through smart monitoring: Built-in Bluetooth lets you track voltage, current, and temperature from your phone via the Renogy DC Home app.
• Lightweight and compact: Easier to handle and install than traditional lead-acid batteries while offering higher usable capacity.
• Maintenance-free design: No need for water refills or complex upkeep—just install and use.
• Enhanced safety: Equipped with an advanced Battery Management System (BMS) that protects against overcharging, over-discharging, short circuits, and temperature extremes.

Features

• 12V 200Ah capacity (2560Wh) for reliable, steady power output.
• Integrated Bluetooth module for wireless performance monitoring.
• Advanced BMS ensures optimal battery protection and performance.
• Lightweight lithium iron phosphate (LiFePO4) chemistry—only about 24kg (52.9 lbs).
• Compatible with solar, RV, marine, and off-grid systems.
• Supports parallel connection for expanded energy storage.
• Maintenance-free operation with zero toxic fumes or acid leakage.

Specifications

• Battery Type: Lithium Iron Phosphate (LiFePO4)
• Nominal Voltage: 12.8V
• Nominal Capacity: 200Ah
• Energy: 2560Wh
• Cycle Life: 4000+ cycles at 80% Depth of Discharge (DOD)
• Max Continuous Discharge Current: 200A
• Max Charge Current: 100A
• Recommended Charge Voltage: 14.4V
• Discharge Cut-Off Voltage: 10V
• Battery Management System (BMS): Built-in, with Bluetooth monitoring
• Communication: Bluetooth (Renogy DC Home App)
• Operating Temperature: Charge: 32°F to 131°F (0°C to 55°C); Discharge: -4°F to 140°F (-20°C to 60°C)
• Storage Temperature: 23°F to 95°F (-5°C to 35°C)
• Weight: 24kg / 52.9 lbs
• Dimensions: 20.6 x 9.4 x 8.8 in (522 x 240 x 224 mm)
• Certifications: UN38.3, CE, RoHS
• Warranty: 5 Years
