Rover Lite 12V/24V/36V/48V 60A MPPT Solar Charge Controller

Overview

The Rover Lite 60A MPPT Solar Charge Controller is built for high-performance off-grid systems that demand efficient, intelligent charging. Designed to handle up to 60 amps and multiple battery voltages, it maximizes energy harvest from your solar array while protecting your batteries from overcharging or damage. Ideal for cabins, RVs, boats, and home backup systems, this controller ensures your solar power runs safely and efficiently — all day, every day.

Benefits

• Charge your batteries faster and more efficiently with advanced MPPT technology.
• Maximize power output even in cloudy or variable sunlight conditions.
• Automatically adjusts to different system voltages (12V, 24V, 36V, or 48V) for versatile use.
• Protects your system from overcharging, short circuits, and reverse polarity.
• Simple setup and monitoring with user-friendly display and LED indicators.
• Extend the lifespan of your batteries with intelligent charging algorithms.

Features

• Maximum Power Point Tracking (MPPT) technology with up to 99% tracking efficiency.
• Supports multiple battery types, including Gel, AGM, Flooded, and Lithium (LiFePO?).
• Automatic system voltage recognition: 12V, 24V, 36V, or 48V.
• Comprehensive electronic protection for overcurrent, short circuit, and reverse connection.
• Real-time system data via LCD screen and LED status indicators.
• Die-cast aluminum design for superior heat dissipation and long-term durability.
• RS485 communication port for remote monitoring and connection to Renogy accessories.

Specifications

• Rated Charge Current: 60A
• System Voltage: 12V / 24V / 36V / 48V (Auto Detection)
• Rated Load Current: 20A
• Max PV Input Power:
  • 12V system: 800W
  • 24V system: 1600W
  • 36V system: 2400W
  • 48V system: 3200W
• Max PV Input Voltage: 100V (25°C), 90V (at full load)
• Battery Voltage Range: 8V–68V
• Charging Algorithm: 4-stage (Bulk, Boost, Float, Equalization)
• Operating Temperature: -35°C to +45°C (-31°F to 113°F)
• Temperature Compensation: -3mV/°C/2V (Lead-Acid only)
• Communication Port: RS485 (RJ45 interface)
• Enclosure Material: Die-cast Aluminum
• Protection Rating: IP32
• Dimensions: 11.4 × 7.8 × 3.2 in (290 × 198 × 81 mm)
• Weight: 5.5 lbs (2.5 kg)
• Certifications: CE, RoHS, FCC
• Warranty: 2 Years
