200W 12V Monocrystalline Solar Bundle Kit
Overview
The 200W 12V Monocrystalline Solar Bundle Kit is the perfect starter package for off-grid power or solar expansion.
Whether you’re upgrading an existing setup or building your first solar system, this kit includes all the essential components to start generating clean, renewable energy.
Compact, efficient, and reliable — it’s ideal for RVs, cabins, boats, or small off-grid projects.
Benefits
- Generate reliable power anywhere with two high-efficiency 100W solar panels.
- Expand your solar setup easily — everything connects seamlessly out of the box.
- Reduce your electricity costs and dependence on the grid.
- Built for long-term use with durable materials and weather-resistant construction.
- Simple to install and maintain for anyone building an entry-level solar system.
Features
- Includes all major components: solar panels, PWM charge controller, branch connectors, and adapter cables.
- High-efficiency 100W monocrystalline panels deliver strong power output even in low-light conditions.
- 30A PWM charge controller protects batteries from overcharging and short circuits.
- Plug-and-play connectors simplify setup — no special tools required.
- Compact design fits perfectly in small or mobile power systems.
Specifications
-
Solar Panels (2 × 100W Monocrystalline)
- Maximum Power (Pmax): 100W per panel
- Open-Circuit Voltage (Voc): 24.3V
- Short-Circuit Current (Isc): 5.21A
- Optimum Operating Voltage (Vmp): 20.4V
- Optimum Operating Current (Imp): 4.91A
- Maximum System Voltage: 600V DC
- Dimensions: 41.8 × 20.9 × 1.4 in
- Weight: 6.4 kg (14.1 lbs)
-
30A PWM Charge Controller
- Nominal Voltage: 12V DC
- Rated Charging Current: 30A
- Max PV Input Power: 400W
- Max PV Input Voltage: 25V DC
- Working Temperature: -20°F to 113°F
- Dimensions: 6.45 × 4.31 × 1.76 in
-
Solar Panel to Controller Adaptor Kit (1 Pair)
- Length: 9 in
- Wire Gauge: 12 AWG
- Voltage Rating: 600V / 1000V
- Temperature Range: -40°F to +185°F
- Protection: IP65
- Conductor: Tinned Copper Wire
-
Solar Y-Branch Connectors (1 Pair MMF + FFM)
- Withstanding Voltage: 1000V DC (TUV) / 600V (UL)
- Contact Resistance: ?1m?
- Protection Degree: IP67 (mated)
- Wiring Size Range: 10 / 12 / 14 AWG
- Insulation Material: PC / PA
- Contact Material: Silver-plated Copper
- Temperature Range: -40°F to +194°F
