ALPHA 4 — 24V 100Ah LiFePO4 Deep Cycle Battery
Overview
The ALPHA 4 is a rugged, long-lasting 24V LiFePO4 battery designed for off-grid, marine, RV, and backup power use. It delivers 2560Wh of usable energy, built?In temperature management for reliable cold? weather starts, and an integrated BMS for safe, stable performance. IP65 protection and a 5-year warranty make it a practical choice when dependable, low? maintenance power matters.
Benefits
- Reduce replacement and maintenance costs with a battery rated for 5000 cycles — more usable life means fewer upgrades.
- Keep devices and systems running reliably in cold weather thanks to internal heating that activates below 5 °C.
- Avoid unexpected downtime with integrated BMS protection and real?time monitoring for clearer battery status.
- Install and handle more easily than comparable lead?acid options thanks to a relatively light 48.5 lb net weight.
- Use outdoors or in damp environments with confidence due to IP65 protection and flame?retardant ABS housing.
Features
- LiFePO4 cell chemistry for stable voltage, thermal safety, and long cycle life.
- Integrated 100A Battery Management System (BMS) that monitors and protects charging and discharging.
- 100A maximum charge and continuous discharge capability, with a 110A 10?second surge rating.
- CC/CV charging method with a recommended 50A (0.5C) charge current for balanced charging speed and longevity.
- Built?in internal heating that draws external power to keep the battery operating in low temperatures.
- Real?time monitoring to view state of charge and system health (via supported interface).
- Rugged ABS flame?retardant housing and IP65 protection for dust and water resistance.
- Compact footprint and manageable weight suitable for RVs, boats, tiny homes, and backup systems.
Specifications
- Cell Type: LiFePO4 Battery
- Nominal Voltage: 25.6 V
- Nominal Capacity: 100 Ah
- Nominal Energy: 2560 Wh
- Cycle Life: 5000 cycles
- BMS Rating: 100 A
- Maximum Charging Current: 100 A
- Maximum Continuous Discharge Current: 100 A
- Maximum Discharge Current (10s): 110 A
- Charge Method: CC/CV
- Charge Voltage: 14.4 V ± 0.2 V
- Recommended Charge Current: 50 A (0.5C)
- Charge Temperature: 0 °C to 55 °C (32 °F to 131 °F)
- Discharge Temperature: -20 °C to 60 °C (-4 °F to 140 °F)
- Storage Temperature: -10 °C to 35 °C (14 °F to 95 °F)
- Self?Heating External Power Draw: 100 W
- Internal Heating Starts: < 5 °C (< 41 °F)
- Internal Heating Stops: > 10 °C (> 50 °F)
- Net Battery Weight: 48.5 lb
- Size (L × W × H): 20.9 × 8.1 × 8.5 in
- Housing Material: ABS (Flame Retardant Plastic)
- Protection Class: IP65
- Warranty: 5 Years
