Compact 400W RV Solar Kit — 4 × 100W Panels with Plug-and-Play Cables
This ready-to-install solar kit bundles four high-efficiency 100W monocrystalline panels with pre-assembled extension cables and a parallel connector pair. It’s designed for RVs, trailers, and vans to provide reliable daytime charging with a straightforward, no-crimp installation.
Benefits
- Keep your batteries topped up while parked or on the road so you can run lights, fans, and small appliances without using the generator.
- Reduce fuel and generator runtime, saving money and cutting noise on trips.
- Fast, tool-free setup gets you going sooner — spend less time wiring and more time traveling.
- Easy to expand: add more panels or accessories without rewiring, thanks to plug-and-play compatibility.
- Long-term confidence with a 25-year output warranty, lowering worry about premature performance loss.
Features
- Four 100W monocrystalline solar panels with anti-reflective coating for improved light absorption and efficiency.
- Pre-assembled 30 ft #10 gauge extension cables (one red, one black) with male and female connectors for quick connections.
- Includes one pair of parallel (2-to-1) connectors to combine panel outputs safely and simply.
- Plug-and-play wiring harness eliminates the need for crimping tools or complex on-site connections.
- Designed for rooftop mounting on RVs, trailers, and vans; lightweight panels for easier handling during installation.
Specifications
- Kit contents: 4 × 100W solar panels; 1 × 30' #10 gauge red extension cable (pre-assembled with female and male connector); 1 × 30' #10 gauge black extension cable (pre-assembled with male and female connector); 1 × parallel connector pair (2-to-1)
- Panel type: Monocrystalline solar cells with anti-reflective coating
- Maximum Power (Pmax): 100 W (per panel)
- Maximum Power Voltage (Vmp): 18.6 V
- Maximum Power Current (Imp): 5.38 A
- Open Circuit Voltage (Voc): 22.8 V
- Short Circuit Current (Isc): 5.78 A
- Maximum series fuse rating: 15 A
- Weight: 13.2 lb (per panel)
- Dimensions (L × W × H): 39.0 × 21.3 × 1.2 in (per panel)
- Warranty: 25-year output warranty
