4 MPPT Hybrid Solar Inverter System
Overview
Reliable, scalable power for grid-tied, off-grid, and hybrid solar setups. It features 4 MPPTs, up to 18 kW PV input, and supports up to 600 V PV input with a battery voltage range of 120–500 V. It delivers 120/240 V AC output for flexible power management. It can be paralleled with up to 3 inverters. A generator can back up the grid during outages. A cloud platform handles remote troubleshooting and updates. It’s designed to fit a range of standards for reliable operation.
Benefits
- High voltage flexibility: 4 MPPTs, 18 kW PV input, up to 600 V PV input, battery 120–500 V, 120/240 V AC output.
- Scalable power: Up to 3 inverters in parallel.
- Generator compatibility: Generator can serve as the grid source during outages.
- Cloud platform: Remote troubleshooting, firmware updates, and system management.
- Comprehensive integration: Works with grid-tied, off-grid, and hybrid setups.
- Compliance ready: Meets major standards and safety requirements.
Features
- 4 MPPTs for flexible solar array management
- 18 kW PV input rating
- Supports up to 600 V PV input
- Battery voltage range 120–500 V
- 120/240 V AC output
- Parallel operation with up to 3 inverters
- Generator compatibility to back feed during outages
- Cloud platform for remote diagnostics and updates
- Hybrid, grid-tied, and off-grid capability
- Industry-standard compliance coverage
Specifications
- MPPTs: 4
- PV input: up to 18 kW
- PV input voltage: up to 600 V
- Battery voltage range: 120–500 V
- AC output: 120/240 V
- Parallel capability: Up to 3 inverters
- Generator compatibility: Yes
- Cloud platform: Yes (remote management and updates)
- System types: Grid-tied, off-grid, hybrid
- Compliance: UL1741 SB, UL1741 SA, IEEE 1547.1-2020, UL1699B, UL1998, FCC Part 15 Class B, California Rule 21, HECO Rule 14H (pending), NEC 690.12-2020, CAN/CSA C22.2 No. 2107.1-1
